TheoLt Core

BENEFITS

Built around standard DWG platforms, TheoLt puts your drawing at the heart of the measurement process. TheoLt is the original direct to CAD interface for Total Station Theodolite (TST). With development dating from 1994 it is second to none as a field proven, easy to use, survey method: no coding, no maths, just simply trace with your instrument straight into your drawing!

TheoLt Core is the part of the TheoLt Suite that provides the link between the software, the CAD platform and Survey instruments.

SUPPORTED INSTRUMENTS
  • Leica T460D+Disto
  • Leica TM1100+Disto/DIOR
  • Leica TC 300/400/500/800
  • Leica TCA1100
  • Leica Builder RM/200/300/400/500
  • Leica TPS Series
  • Leica Flexline TS
  • MDL LaserACE 300
  • Trimble 5600 (Geodimeter CU)/ S6
  • Topcon GPT-1000/GPT-6000/GPT-2006
  • Sokkia SET330r/SET530r/SET630r/SET2
  • Leica Disto Memo/Plus/A6/D3aBT/A8/D8
  • Nikon NPL/700
  • Zeiss ELTA3
MAJOR FUNCTIONS
  • Project manager
  • Default Orientation (to Plane)
  • Orientation by reference
  • Orientation by resection
  • Measurement History window
  • Set relative reference datum
  • Circle and arc through 3D-points
  • User definable feature library
SUPPORTED PLATFORMS
  • BricsCAD®  V10-V15 (32 and 64Bit)
  • AutoCAD® 2007-2015 (32 and 64Bit)
DOWNLOADS

Download a trial.
